Table6.Statusindicators(continued)

IndicatorMeaning

Slowblinkingred:Thecomputerisinsleep(standby)mode.

Off:

Thecomputerisofforinhibernation

mode.

On-screenindicators

Capslock:

CapsLockmodeisenabled.Y oucan

enterallalphabeticcharacters(A-Z)in

uppercasewithoutpressingtheShiftkey.

Wirelessstatus:PressF9toenableordisablethewireless

features.Y oucanquicklychangethe

powerstateofeachfeatureinthelist.

50HardwareMaintenanceManual
