RemovalstepsoftheBluetoothdaughtercard

StepScrew(quantity)Color

Torque

M2×3mm,wafer-head,nylon-coated(1)

Black0.181Nm

(1.85kgf-cm)

Wheninstalling:Makesurethattheconnectoronbottomsideofthecardisattachedrmlytothesystem

board.

1130Keyboard

Foraccess,removetheseFRUsinorder:

•“1010Batterypack”onpage58

•“1020Opticaldriveortravelcover”onpage58

•“1090Palmrestassemblywithcables”onpage69

Chapter8.RemovingorreplacingaFRU75
