-45

Adjustments and Settings

Adjusting the Colour

Temperature

This function allows for selecting the desired

colour temperature. With the lower value se-

lected, the projected image becomes warmer,

reddish and incandescent-like while with the

higher value, the image becomes cooler, blu-

ish and fluorescent-like.

Select “CLR Temp” in the “Picture”

menu on the menu screen.

➝For operating the menu screen, see

pages 38 to 41.

On-screen Display

5500K

6500K

7500K

8500K

9300K

10500K

Selected Item

Description

The less the value is set to, the

warmer, reddish, incandescent-like

the image becomes.

The more the value is set to, the

cooler, bluish, fluorescent-like the

image becomes.

“CLR Temp” is fine adjusted by following the

procedure below.

1 Select “CLR Temp” in the “Pic-

ture” menu on the menu

screen and press

.

• A single menu bar of “CLR Temp” is

displayed.

2 Press

''

''

' or

""

""

" to fine adjust the

colour temperature.

• With the lower value selected, the pro-

jected image becomes magenta-

tinged. With the higher value selected,

the projected image becomes green-

tinged.

• Pressing \ or | changes the value

of the colour temperature in the sub

menu.

Note

•Values on “CLR Temp” are only for gen-

eral standard purposes.

XV_Z200E_E_p44_50.p65 03.10.30, 13:14PM45
