5 - 37 AR-651/810 TROUBLE SHOOTING

5. 1. 6. Paper jam in finisher

[E9F] Punching jam

Is there any paper remaining on the transport path in the finisher or main unit?

YES

Remove the paper.

Is the connector J1 on the punch driver PC board disconnected?

Is the harness connecting the punch driver PC board and punch home position sensor

(PI3P) open-circuited?

YES

Connect the connector securely. Replace the harness.

Is the punch home position sensor working properly?

1. Connect the connector of the punch home position sensor securely.

2. Replace the punch home position sensor.

YES

Replace the punch driver PC board.

[EA1] Finisher paper transport delay jam

Is there any paper remaining on the transport path in the finisher or main unit?

YES

Remove the paper.

Is the connector J17 on the finisher controller PC board disconnected?

Is the harness connecting the finisher controller PC board and inlet sensor (PI1) open-circuited?

YES

Connect the connector securely. Replace the harness.

Is the inlet sensor working properly? (Check the movement of the actuator.)

1. Connect the connector of the inlet sensor securely.

2. Attach the actuator securely if its shaft is out of place.

3. Replace the inlet sensor.

YES

Replace the finisher controller PC board.
