AR-651/810 TROUBLE SHOOTING 5 - 30

[E58] Trailing edge of paper not passing the reverse sensor 1/2

Is there any paper at the reverse section when the exit cover is opened?

Remove the paper.

Is the reverse sensor 1/2 working? (Perform the input check in the test mode: 03-[ENERGY

SAVER]OFF/[2]/[B], [2]/[C])

1. Check if the connector of the reverse sensor 1/2 is not disconnected.

2. Check if the connector J335 on the LGC board is not disconnected.

3. Check if the connector pins are not disconnected and the harness is not

open-circuited.

4. Check if the conductor pattern on the LGC board is not short- or open-

circuited.

5. Replace the reverse sensor 1/2.

6. Replace the LGC board.

1. Check if the setting of the paper size is correct.

2. Check the condition of the roller at the reverse section and clean it, or if it is deteriorated,

replace it.

3. Check if there is no mechanical loading at the follower roller and no abnormality at the myler.

4. Check if the adjustment of the reverse motor speed (05-426/427) is appropriate.

YES
