14 GDI (GDI PWB Unit)

NO. PARTS CODE

PRICE RANK

NEW

MARK

PART

RANK

DESCRIPTION

Ex. Ja.

AH DX C

Connector (36pin) [CN202]

2 AF DS C

Connector (27pin) [CN203]

3 AD DJ C

Coil (SBO-02SAN) [L201,203]

4 AA DD C

Capacitor (50WV 100PF)

[C222,224∼230,237∼241]

5 AA DD C

Capacitor (50WV 33pF) [C233,234]

6 AA DD C

Capacitor (50WV 560PF) [C235]

7 AB DD C

Capacitor (10WV 47µF) [C203]

8 AA DD C

Capacitor (25WV 4.7uF) [C201]

9 AA DD C

Capacitor (25WV 0.10µF) [C206,223,231,236,242]

10 AA DD C

Capacitor (50WV 1000PF) [C232]

11 AB DD B

Diode (DAP202K) [D201∼209]

12 AH DX B

IC (74LS244NS1) [IC206,207] IC

AF EB B

IC (74LS245NS1) [IC205] IC

AA DD C

Resistor (1/2W 100Ω±5%) [R201]

15 AA DD C

Resistor (1/10W 1.0KΩ±5%) [R227,230]

16 AA DD C

Resistor (1/10W 10KΩ±5%) [R247∼250]

17 AA DD C

Resistor (1/10W 1.2KΩ±5%)

[R213,215,218,220,222,224,226,229,231,234,235,238]

18 AA DD C

Resistor (1/10W 22Ω±5%)

[R214,216,217,219,221,223,225,228,232,236,237,240∼244]

19 AA DD C

Resistor (1/10W 3.3KΩ±5%) [R239]

(Unit)

901

BL HL N E

GDI PWB unit GDI

15 (Power Supply PWB Unit)

NO. PARTS CODE

PRICE RANK

NEW

MARK

PART

RANK

DESCRIPTION

Ex. Ja.

(Unit)

901

BN HZ E

Power supply PWB unit (100V Japan)

BP LP N E

Power supply PWB unit (120V USA)

16 (High Voltage PWB Unit)

NO. PARTS CODE

PRICE RANK

NEW

MARK

PART

RANK

DESCRIPTION

Ex. Ja.

AR EQ B

IC (A2918SWH) IC

(Unit)

901

BK HG E

High voltage PWB unit (Japan)

BL HL N E

High voltage PWB unit (USA)

– 8 –
