Sharp 32" LED TV
www.sharpusa.com
Installing the stand or wall-mount bracket
Installing the stand
To install the stand:
1 Secure the stand column to the base using the four provided M4 (14 mm) screws. (These are the long screws.)
2 Carefully place your TV face-down on a cushioned, clean surface to protect the screen from damages and
scratches.
Notes
If you plan to wall-mount your TV, do not install the stand.
Store the stand and stand screws in case you decide to use the stand in
the future.
Screw type Screw length # of screws
M4 14 mm 4
