LC-32LB150U Sharp 32" LED TV

www.sharpusa.com

3 Insert the stand column into the TV.

4 Secure the TV stand to your TV with the four provided M4 (10 mm) screws. (These are the short screws.)

Installing a wall-mount bracket

To attach your TV to a wall-mount bracket:

1 Carefully place your TV face-down on a cushioned, clean surface to protect the screen from damages and

scratches.

Screw type Screw length # of screws

M4 10 mm 4

Warning

• This TV is intended to be supported by a UL Listed wall mount bracket

with suitable weight/load. (See “Miscellaneous” on page 74.)

• To prevent injury, this apparatus must be securely attached to the

floor/wall in accordance with the installation instructions.
