7
Sharp 32" LED TV
www.sharpusa.com
2 If the TV stand is attached, remove the four screws that secure the stand to your TV.
3 Remove the TV stand.
4 Remove the screws in the mounting holes on the back of your TV, then follow the instructions that came with
the wall-mount bracket.
Notes
The length of the wall-mount screws vary depending on the wall-mount
bracket you purchased. See the instructions that came with the
wall-mount bracket for screw lengths.
The mounting holes on the back of your TV take type M6 screws.
3.94 in. (100 mm)
3.94 in. (100 mm)
Wall-mount
brackets
