Using Your Notebook 3-7

CD-ROM Drive

The built-in CD-ROM drive is accessible on the left side of the notebook. The drive

supports all of the major compact discs, including CD-DA, CD-ROM XA

(ADPCM), CD-I and Photo CD (multisession). You can use the drive to play music

CDs, install and run programs, or you can install a battery pack in place of the CD-

ROM drive.

The Sharp Player software provided with the computer allows you to use CDs. See

the online help included with the software for use instructions.

Installing the CD-ROM Drive

Follow the steps below to replace a battery pack with the CD-ROM drive.

1. Turn off the power, then unplug the AC cord.

2. Place the notebook on a flat surface. While holding its left side, turn it upside

down.

3. Slide the retaining levers inward and remove the battery.

Figure 3-2. Removing the Battery Pack
