Attaching and Replacing an External Display
Connecting the External Display to the Computer
Warning:
Do not disconnect the external
display while the computer is in
suspend mode or hibernation
mode. If no external display is
attached when the computer
resumes, the LCD will remain
blank and the output will not be
displayed. It does not depend on
the resolution value.
To attach an external display to the computer, do the following:
1
Turn off the computer.
2
Attach the external display to the external display
connector (
) as shown.
2
3
1
3
Turn on the external display and the computer.
Chapter 6. Installing and Removing Options 169
