Using the Mwave DSP Telephony Features
2
Double-click on the Modem 14400 icon.
The Mwave modem starts automatically, and the following
modem window appears:
MwaveModem14400
Actions
Help
MRDTRSDRDOHCDAAHS
Ready
3
Start your communication program.
Stopping the Modem:
When you finish using the communication programs, turn off the
modem to free the Mwave DSP resources for other functions. To
turn off the modem, do the following:
1
If the modem window is minimized, double-click on the
icon to maximize it.
2
Select Close from the window pull-down menu.
DOS
For DOS
To start the Mwave modem, do the following:
Type MWMODEM ON at the DOS prompt; then press
Enter.
Stopping the Modem:
When you finish using the communication programs, turn off the
modem to free the Mwave DSP resources for other functions. To
turn off the modem:
Type MWMODEM OFF at the DOS prompt; then press
Enter.
86 IBM ThinkPad 755CX User's Guide
