Installing the DAA/Telephony Kit
Installing the DAA/Telephony Kit
Note:
In some countries, the Mwave
telephony functions are available
after the DAA/Telephony Kit option
is installed.
If the telephone plug on the left side of your computer is one with a
square receptacle, the computer can be used for telephony or
modem/fax functions without any changes. However, if a dummy
connector plug is attached, you need to install the DAA/Telephony
Kit into your computer to use the Mwave telephony functions.
To attach the DAA/Telephony Kit, do the following:
1
Turn off the computer; then open the port cover on the
left side of the computer.
Warning:
Make sure the locking lever for
the hard disk drive is unlocked.
2
Open the keyboard.
Chapter 6. Installing and Removing Options 155
