43

REMOVING MISFEEDS

BYPASS TRAY (MX-MFX1) / LARGE CAPACITY TRAY

When a mark below blinks, a misfeed has occurred at that location.

X Bypass tray (MX-MFX1)

1

Remove the misfed paper.

2

Open the bypass tray.

Push the lever on the top of the

tray to the left to release the

lock.

3

Remove the misfed paper.

4

Close the bypass tray.

X Large capacity tray (MX-LCX3N)

1

Open the cover.

2

Remove the misfed paper.

After removing the paper, close

the cover.

3

Open the bypass tray cover.

Bypass tray

(MX-MFX1)

Large capacity tray

(MX-LCX3N)/

Large capacity tray

(MX-LCX6)

(page 44)
