11

REPLACING THE STAPLE CARTRIDGE

SADDLE UNIT

1

Open the cover.

2

Pull out the unit.

Slowly pull out the unit until it

stops.

3

Remove the staple case.

(1) Grasp the green part and

pull it forward and down.

The unit that holds the

staple case will move

forward.

(2) Pull the staple case up

and out.

4

Release the staple case cover lock.

While holding both sides of the

staple case, pull up the upper

unit.

5

Remove the staple cartridge.

6

Install a new staple cartridge.

Push the staple cartridge in until

it clicks into place.

7

Push the staple case firmly back in.

8

Pull the seal that holds the staples

straight out.

Replace the cartridges in the front and back staple

cases (two cartridges).

When staples remain, the lock cannot be released.

(1)

(2)

Do not remove the seal from the cartridge before

inserting the cartridge into the case.
