37

REMOVING MISFEEDS

19

Remove the misfed paper.

When released, the paper guide

automatically returns to its

original position.

20

Pull the paper guide up in the direction

of the arrow.

21

Remove the misfed paper.

When released, the paper guide

automatically returns to its

original position.

22

Return the unit to its original position

and close the cover.

X Transport area

1

Open the cover.

2

Open the paper guide.

While pressing on the green

release button, open the paper

guide in the direction of the

arrow.

3

Remove the misfed paper.

Misfeed in tray 1 or tray 2

Misfeed in tray 3

Misfeed in tray 4

4

Close the paper guide and close the

cover.
