OPTIONAL EQUIPMENT

SINGLE PASS FEEDER (AR-

SP4)/REVERSING SINGLE

PASS FEEDER (AR-RP3)

The single pass feeder (SPF) and the reversing single pass feeder (RSPF) hold up to 30 originals each

for automatic document feeding.

If the RSPF is installed, two-sided originals can be copied automatically without having to manually turn

them over.

Part names

Exit area

Reversing tray

Right side cover

AR-SP4

AR-RP3

Exit area

Original guides

Document feeder tray

Feeding roller cover

Original guides

Document feeder tray

Feeding roller cover

00.book 93 ページ２００１年４月２０日金曜日午後９時３４分
