STATUS INDICATORS

TD cartridge replacement

TD CARTRIDGE REPLACEMENT

Remove the protective cover from the TD cartridge by

unlatching three cover hooks from the holes on the

cartridge and then pulling the cover in the direction

indicated by the arrow in the illustration.

Gently insert the TD cartridge along the guides until it

locks in place.

If dirt or dust is adhered to the TD cartridge, remove it

before installing the cartridge.

Close the front cover by pushing both sides with your

hands and then close the side cover by pressing the

handle on the cover. The indicator will go out .

When closing the covers, be sure to close the front

cover securely and then close the side cover. If the

covers are closed in the wrong order, the covers may

be damaged.
