Digital Still Camera Features
75
Red-eye indicator
Red-eye Reduction
Available mode:
Card Camera
Red-eye reduction allows you to minimize
the camera flash capturing the red at the
back of the iris.
1 In Card Camera mode, press the
DISPLAY button until the mode
screen appears.
2 Select “MENU”, then “EXECUTE” by
using the Operation button (see page
32).
3 Press l or m to select Y, then
press the centre of the Operation
button.
4 Make sure the flash mode is set to
“AUTO” or “ON”. If not, set to either
one (see page 74).
5 Press l or m to select “RED EYE”,
then press the centre of the Operation
button.
6 Press l or m to select “CORRECT”,
then press the centre of the Operation
button.
SETT ING 1
RETURN
FLASH
REC MODE
IMAGE SI ZE
RED EYE
OFF
CORRECT
F I LE NO.
0821
][
/
911
NORMAL
CORREC TRED EYE
7 Press the DISPLAY button to turn off
the menu screen.
• Red-eye indicator appears when
on-screen indicators are turned
on.
Notes:
• The flash fires twice when the red-eye
reduction is set to “CORRECT”. The first flash
is to reduce the “red-eye”, and the second
flash is for recording the still image.
• The effect of red-eye reduction depends on
individual. Reduction may not be as effective
as desired on conditions like shooting
distance or the subject not watching the pre-
flash.
• Red-eye cannot be used when the flash is
set to “OFF”.
