Outstanding Features

Image Quality and Functions

Reliability/Durability

The PN-V601 and PN-L601B feature a full-array LED backlight to

provide uniform screen brightness. The PN-T321’s edge-lit LED

backlight gives the monitor an extremely thin prole.

LED Backlight

Picture-in-Picture mode allows an AV-sourced image to be

displayed within a PC-sourced one (or vice versa). Picture-by-

Picture mode puts images from AV and PC sources side by side.

Dual Screen Display

The Enlarge (Zoom) Display Mode

permits multiple monitors to be

grouped together to display one enlarged image.

Used with PC and AV signal output on PN-V601.

Enlarge (Zoom) Display Mode

With Mirror Display mode, the same image can be displayed on a

daisy chain of PN-V601, PN-E Series, and PN-L601B monitors for

the powerful impact of visual repetition.

Mirror Display Mode (Daisy Chain)

The Brightness Sensor function ensures clear visibility by

automatically adjusting backlight brightness to complement

surrounding brightness levels. In dark surroundings, backlight

brightness automatically lowers, providing optimal viewing and

energy savings as well.

Brightness Sensor

Designed for around-the-clock use, Sharp LCD monitors are a

reliable and commanding presence in 24-hour stores, surveillance

rooms and other demanding applications.

24/7 Operation

Fanless architecture

maintains airow and dissipates heat without

the use of mechanical air-ventilation fans, which can attract dust

and create noise.

Excluding PN-V601

Fanless Architecture

The Power on Delay function allows a time delay between the

startup of each monitor in a multi-monitor installation. This helps

reduce the load placed on the power supply when a number of

monitors are turned on simultaneously.

Power on Delay

Should the temperature inside a monitor rise, a built-in sensor will

automatically adjust the backlight to keep the temperature within

operation level.

The monitor automatically goes to standby mode when the internal temperature remains

consistently above operational levels.

Built-In Temperature Sensor

The LCD panels for the PN-E601/E521/L601B incorporate

A technology

. In addition to eliminating light leakage from

the backlight, this technology also enables the most efcient use

of light from the backlight, thereby helping save energy while

displaying bright whites, deep blacks and vivid colors.

A stands for “Ultraviolet-induced multi-domain Vertical Alignment,” a photo-alignment

technology that ensures uniform alignment of liquid crystal molecules in a certain direction.

A Technology

In dark surroundings In bright surroundings

PC display AV displayAV display PC display

• Picture-in-Picture mode • Picture-by-Picture mode

Single-monitor display Enlarged four-monitor display
