Program Editor

4. Set [Frame Layout].

1) Checkthecheckboxesbesidetheframes,scroll

messages, or PIP that you want to display.

 Youcanalsoclickthe button at the top right

hand corner of a frame or scroll message to hide it.

2) Set“X”,“Y”,“Width”,and“Height”coordinatesforeach

frame or scroll message.

 •Only“X”and“Y”coordinatescanbeadjustedfor

thePIPframe.ToadjustthesizeofthePIPframe,

clickthe[PinP]tab,andspecifya“Value”forthe

“Size”under“Key”.

•Clickonaframeorascrollmessagetoselectit.

Eightresizehandleswillappeararoundtheborder

of the frame. By dragging these handles with the

mouse,youcanresizeaframeorscrollmessage,

andconﬁrmchangesvisually.

The frame and scroll messages can be moved by

dragginganareaotherthantheresizehandleusing

the mouse.

· Draggingwhileholdingdown[Shift]allowsyoutoresizeaframewhilekeepingthesameaspect

ratio.

· Youcanalsomoveframesorscrollmessagesusingthearrowkeys.

Youwillstillbeabletoadjustthesizeofaframeifyouholddown[Shift]whileusingthearrowkeys.

 •Youcanmoveorresizeitemsaccuratelybyaligningthemwiththegrid.(

p.33)

E.g.

Frame1: X=25, Y=20, Width=1338, Height=835

Frame2: X=1380, Y=25, Width=523,  Height=830

Message1: X=20, Y=869, Width=1883, Height=194

PIP: X=576, Y=395

The above coordinates would produce a layout like the screenshot below.

 •Thename,positionanddimensions

(Xcoordinateoftopleftcorner,

Ycoordinateoftopleftcorner,width,

height) are displayed in the top left of

each frame or scroll message.

•ThePIPframecannotbemovedin1pt

increments.Locationswhereitemscan

be positioned depend on the kind of

LCDmonitorused.

Creating programs
