5. Select the “Custom” option button, and click [Next].

6. Select the “All programs” option button, and click [Next].

7. From the “Protocol type” list, select “ICMPv4”.

8. Set “Protocol and Ports”, “Scope”, “Action”, and

“Prole” in order as necessary. Click [Next] to be taken

to the settings screen for the next step.

 Conﬁrmwithyournetworkadministratorbefore

adjustingthesesettings.

9. Enter a “Name”, and click [Finish].

10. Close the dialog boxes by clicking the

button at

the top right of each window.

Installing SHARP Digital Signage Software
