14. MX-RB15 Curl Correction Unit

Corrects paper curling by putting pressure

on the convex/concave curl.

15. MX-CF11 Inserter (200-sheet x 2 bin)

Requires MX-FD10 or MX-RB13.

SRA3 - A5R, 200 sheets each (80 g/m

)

16. MX-FD10 Folding Unit

Required if MX-CF11 is installed and

MX-RB13 is not required.

Folding options include Z, C, accordion,

double and half folds.

17. MX-RB13 Relay Unit

(between 100-sheet staple ﬁnisher and inserter)

Required if MX-CF11 is installed and MX-FD10 is not required.

18. MX-FN21 Finisher (4k - 100-sheet staple)

A3 - B5 (offset/staple), SRA3 - A5R (non offset)

Upper tray: 1,500 sheets*

Middle tray: 250 sheets*

Lower tray: 2,500 sheets*

100-sheet* staple capacity

(front, rear or 2 point stitching)

19. MX-FN22 Saddle Stitch Finisher (4k - 100-sheet staple)

A3 - B5 (offset/staple), SRA3 - A5R (non offset)

Upper tray: 1,500 sheets*

Middle tray: 250 sheets*

Lower tray: 2,500 sheets*

100-sheet* staple capacity

(front, rear or 2 point stitching)

Saddle stitch tray: 5 sets (16-20 sheets),

10 sets (11-15 sheets), 15 sets (6-10 sheets),

25 sets (1-5 sheets). Max 20 sheets per set.

MX-TM10 Trimming Module (for MX-FN22)

Up to 20 mm trim width, 1,500 sheets (80 g/m

)

MX-PN13A/C/D Punch Module (for MX-FN21 & MX-FN22)

A: 2 hole punch, C: 2/4 hole punch, D: 4 hole wide punch

Faxing

MX-FWX1 Internet-Fax Expansion Kit

MX-FX11 Fax Expansion Kit

Super G3 fax module.

Connectivity

Printing

MX-PF10 Barcode Font Kit

Enables barcode printing.

MX-PUX1 XPS Expansion Kit

Enables XPS printing.

MX-AM10 Web Browsing Expansion Kit

Enables Internet browsing from the control panel.

Scanning

AR-SU1 Stamp Unit

Marks already scanned documents for checking.

MX-EB11 Enhanced Compression Kit

Enables creation of high compression PDFs.

Sharpdesk Licenses

MX-USX1/X5/10/50/A0

1/5/10/50/100-License Kit

Sharp OSA

MX-AMX1 Application Integration Module

MX-AMX2 Application Communication Module

MX-AMX3 External Account Module

Sharp OSA Network Scanner Tool Licenses

MX-UN01A/05A/10A/50A/1HA (Requires MX-AMX2)

1/5/10/50/100-License Kit

Security

MX-FR36U Data Security Kit (non CC version)

MX-EB15 Mirroring Kit

Second hard drive enables data backup of ﬁles stored on HDD.

A4 or smaller, 80 g/m

. Some options may not be available in some areas.

Finisher

Folding Unit

Inserter

Saddle Stitch Finisher
