NOTES

At rated voltage. May vary depending on machine conditions and operating environment.

Best achieved time based on A4 copy, long-edge feeding from 1st paper drawer, using document glass, when machine is

ready. May vary depending on machine conditions and operating environment.

Requires optional MX-PUX1.

To view XPS ﬁles on PCs not running Windows Vista, you must have the XPS View application installed.

Requires optional MX-EB11.

Requires optional MX-FX11.

Requires optional MX-FWX1.

Measured using Sharps’ standard chart (A4 with 6% coverage, B/W).The storage capacity will be less for colour pages.

Based on Sharp’s standard chart with approx. 700 characters (A4 portrait) at standard resolution in Super G3 mode,

33,600 bps, JBIG compression.

GENERAL

Resolution (dpi) 1,200 x 1,200, 600 x 600, 9,600 (equivalent) x 600

Memory 5 GB shared

Interface USB2.0, 10Base-T / 100Base-TX / 1000Base-T

Supported OS Windows

XP, Windows Server

2003, Windows Vista

Windows Server

2008, Windows Server

2008 R2, Windows

Mac OS X 10.4.11, 10.5 – 10.5.8, 10.6 – 10.6.8, 10.7 – 10.7.2

Network protocols TCP/IP (IPv4 & IPv6), IPX/SPX (Netware), EtherTalk (AppleTalk)

Printing protocols LPR, Raw TCP (port 9100), POP3 (e-mail printing), HTTP,

Novell Printserver application with NDS and Bindery,

FTP for downloading print files, EtherTalk printing, IPP

PDL emulation Std PCL6, Adobe

PostScript

3™

Opt XPS*

Available fonts

PCL 80

Adobe

PostScript

3™ 136

NETWORK PRINTER

Document filing capacity (pages/or files)

Main folder & Custom Folder 35,000*

or 5,000

Quick file folder 10,000*

or 1,000

Stored jobs Copy, print, scan, fax transmission*

Storage folders Quick folder, main folder, custom folder (max.1,000)

Confidential storage Password protection (for main and custom folders)

Scan method Push scan (via operation panel)

Pull scan (TWAIN compliant application)

Resolution (dpi)

Push scan 100, 150, 200, 300, 400, 600

Pull scan 75, 100, 150, 200, 300, 400, 600, 50 - 9,600 via user setting

File formats XPS*

, PDF, Encrypted PDF, Compact PDF*

, PDF/A, JPEG, TIFF

Scan destinations Scan to e-mail, desktop, FTP server, network folder (SMB),

USB memory, fax*

, i-fax*

Scanner utilities Network Scanner Tool, Sharpdesk

NETWORK SCANNER

Original paper size (Max) A3

First copy time*

(seconds) Colour B/W

MX-7040N 5.1 3.7

MX-6240N 5.6 4.0

Continuous copies (Max) 9,999

Resolution (dpi)

Scan (Colour) 600 x 600

Scan (B/W) 600 x 600, 600 x 400

Print 600 x 600

9,600 (equivalent) x 600 (depending on print mode)

Gradation levels 256

Zoom range (%) 25 – 400 (25 – 200 using DSPF) in 1% increments

Preset copy ratios 10 (5R/5E)

COPIER

Compression method MH/MR/MMR/JBIG

Communication protocol Super G3 / G3

Transmission time*

(seconds) Less than 2

Modem speed (bps) 33,600 – 2,400 with automatic fallback

Transmission resolution (dpi)

Std 203.2 x 97.8

Ultra Fine 406.4 x 391

Recording width A5 – A3

Memory (GB) 1

Grey scale levels 256

FAX (requires optional MX-FX11)

Paper capacity (Std – Max)

Sheets 3,100 – 8,500

Drawers 4 – 6 (plus multi bypass tray)

Warm-up time*

(seconds) 55

Duplex Std

Memory

Copier/Printer (shared) 5 GB

HDD 1 TB

Power requirements Rated local AC voltage ±10%, 50/60 Hz

Power consumption kW (Max) 3.84

Dimensions (mm) (W x D x H) 845 x 844 x 1,222

Weight (kg) 222

Engine speed (ppm/cpm) (Max)

A4 A3

MX-7040N 70 35

MX-6240N 62 32

Paper size (Min – Max)

Drawer 1 & 2 A4

Drawer 3 B5R - A3W

Drawer 4 A5R - A3W

Multi bypass A5R - SRA3

1,200 x 320 mm (Max)

Paper weight (g/m

)

Drawer 1 & 2 60 - 105

Drawer 3 & 4 60 - 220

Multi bypass 55 - 300

833 mm**

1,275 mm

3,628 mm*

Shown with options.

* 3,893 mm with exit tray/multi-bypass tray extended

** 844 mm when control panel is facing upwards.

EXTERNAL DIMENSIONS

DOCUMENT FILING

Design and speciﬁcations are subject to change without prior notice.

All information was correct at time of print. The ENERGY STAR logo is

a certiﬁcation mark and may only be used to certify speciﬁc products that

have been determined to meet the ENERGY STAR programme requirements.

ENERGY STAR is a US registered mark. Windows, Windows XP, Windows

Server and Windows Vista are registered trademarks of Microsoft Corporation

All other company names, product names, and logotypes are trademarks

June 2012 Ref: Brochure MX-7040N/MX-6240N. All trademarks

acknowledged. E&OE.
