115
Shooting Functions
4
You can connect a commercially available stereo microphone to the
microphone input terminal. Using an external microphone may reduce
noise, such as camera operation sounds, that is recorded.
1
Turn the camera off.
2
Open the cover of the
microphone input
terminal and connect the
microphone plug to the
microphone input
terminal.
3
Turn the camera on.
The settings described in this section can also be set through the control panel.
Connecting a Microphone
The following specifications are recommended for external microphones.
• Plug: Stereo mini-plug (∅3.5mm)
• Type: Stereo electret condenser
• Power supply: Plug-in-power system (operating voltage of 2.0V or less)
• Impedance: 2.2kΩ
Note that if the external microphone is disconnected during recording, the
movie recording will be terminated.
