5. TRIMMING/MASKING (Cont.)

Procedure

Using the original scale and the front scale,

read the values defining the desired area

as follows:

. X1 • • Distance from the original scale to the

left edge of the specified area

. X2 • • Distance from the original scale to the

right edge of the specified area

. Y1 • • Distance from the front scale to the

lower edge of the specified area

. Y2 • • Distance from the front scale to the

upper edge of the specified area

Set the above values using the digital keys

and the SET key as described in the

following procedure.

Select the editing function in the Editing

menu.

. Press the EDIT key to enter the Editing menu,

and then press the EDITING key.

Press the TRIM or MASK key.
