MISFEED REMOVAL

When the misfeed ( ) indicator blinks or blinks in the display, the unit will

stop because of a misfeed. When the SPF misfeeds an original sheet, the unit will

stop and the SPF misfeed ( ) indicator will blink, while the misfeed ( ) indicator

will remain off. For a misfeed of originals in the SPF, see "E: Misfeed in the SPF"

(p.67).

Open the multi-bypass tray,

and then open the side

cover.

Check the misfeed location. Remove the misfed paper

following the instructions for each location in the illustration

below. If the misfeed ( ) indicator blinks, proceed to "A:

Misfeed in the paper feed area" (p.64).

If paper is misfed here, proceed to "A:

Misfeed in the paper feed area". (p.64)

If paper is misfed here, proceed to "B:

Misfeed in the fusing area". (p.65)

If the misfed paper is seen from

this side, proceed to "C: Misfeed

in the transport area". (p.66)

If paper is misfed here, proceed

to "D: Misfeed in the lower

paper feed area". (p.66)
