Using the Organizer for the First Time

Be sure to perform the following operations before using the Organizer

for the first time.

1. First, a battery will need to be installed. On the back of the

Organizer, slide the Battery Replacement switch to the “REPLACE

BATTERY” position.

2. Slide out to remove the battery compartment cover.

3. Insert a new battery, making sure to

correctly orient the plus (+) and minus

(-) terminals, as illustrated.

Note:

Inserting a battery with reversed polarity

may damage the Organizer.

4. Slide the battery compartment cover

closed until it snaps into place.

5. Slide the Battery Replacement switch

back to the “NORMAL OPERATION”

position, then press the RESET switch.

The RESET switch is located on the

back of the Organizer. Use the stylus

(attached to the side) to carefully press

down the switch.

Note:

• Do not use an object with a breakable or sharp tip.

6. A dialog “System Reset Clear All Data? Yes No” appears on the

screen. Use the stylus to tap “Yes” on the screen to proceed.

7. Next, a dialog “WARNING! All Data will be LOST Are you sure? Yes

No” appears.

Again, tap “Yes” to proceed.

8. “Memory Reset Please wait...” appears. After a moment, Home

Clock will appear on the screen.

If a malfunction occurs under abnormal conditions

If the Organizer is subjected to strong extraneous electrical noise or

shock during use, on rare occasions, all the functions will not work

properly and data may be displayed incorrectly. In such cases, follow

the procedures shown below.

1. Press the RESET switch.

2. A dialog "System Reset Clear All Data? Yes No" will be displayed.

Tap “No”.

If the above procedure doesn't work, follow the next procedure to

initialize the Organizer's memory. All stored data in the Organizer will

be deleted.

1. Press the RESET switch.

2. When a dialog "System Reset Clear All Data? Yes No" is displayed,

tap “Yes”.

3. When a dialog “WARNING! All Data will be LOST Are you sure? Yes

No” appears, tap “Yes”.

REPLACE BATTERY

•

NORMAL OPERATION

RESET

REPLACE BATTERY

•

NORMAL OPERATION

RESET

OZ590_1206.pm65-p2-9 02.12.6, 9:51 PM2
