Sharp AR-C200P: Maintenance • 331
4. Check that the paper guides and rear stopper are snug against
the paper.
5. Close the paper tray gently.
Important!
To prevent jams:
• Make sure there is no space between the paper and the
paper guides and rear stopper.
• Don’t overfill the paper tray. Capacity depends on the type of
paper and the paper weight (max. 530 sheets of 20 lb. [75
gm²] paper).
• Don’t load damaged paper.
• Don’t mix paper of different sizes, paper quality or thickness.
• Don’t remove the paper tray during printing.
