Sharp AR-C200P: Windows 2000 Operation • 175
Printing Custom Pages Using the PCL Driver
1. Open the file in your application and select File → Print.
2. In the Print dialog box, click the PCL driver on the General tab,
then click the Setup tab.
1. Under Media, select User Defined in the Size drop-down list.
The Set Free Size dialog box appears.
NOTE
Up to 32 custom page sizes can be defined in the PCL driver.
NOTE
You may see a Warning dialog box indicating a conflict. If
you do, click OK and the driver will automatically make the
needed changes to correct for the conflict.
