Printing Lists
131
8. Printing
Lists
Transaction Report print condition
You can change the condition under which a Transaction Report is printed out.
Follow the steps below.
1 Make sure that the date and time
display of fax mode appears (if needed
press ) and then press
2 Press .
3 Press .
4 Press a number from to to select the condition for printing.
5 Press repeatedly to exit.
ALWAYS PRINT A report will be printed after each
transmission, reception, or error.
SEND ONLY A report will be printed after each
transmission.
ERROR ONLY A report will be printed only when an error
occurs.
NEVER PRINT A report will never be printed.
FAX
MENU
The display briefly shows
your selection, then:
1:TX/RX REPORT
(Selections appear alternately)
1: ALWAYS PRINT
Display:
FAX SETTING
2: ACTIVITY LIST
