Loading Paper

You can load approximately 250 sheets of A4 paper (max. 80 g/m

) in the

paper tray.

Caution!

Do not use the blank side of paper that has already been printed on.

1 Remove the output tray.

2 Insert a stack of paper into the tray,

print side up.

• Important! The stack of paper must not

be higher than the paper height line on

the paper tray.

3 Squeeze the sides of the paper guide

as shown and slide it to the slot for the

length of the paper you are loading

(A4).

Paper height line
