Scanning Thick Plastic Cards

[Feed Mode] (fi-7180/fi-7280)

When you use fi-7180/fi-7280 to scan at 300 dpi or less (80

ppm) in landscape, plastic cards with a thickness up to 1.4

mm can be scanned.

1 Start up the Software Operation Panel.

For details, refer to "9.1 Starting Up the Software Operation Panel"

(page 163).

2 From the listing on the left, select [Device Setting 2] 

[Feed Mode].

3 Specify the feed mode.

To scan a plastic card up to 1.4 mm thick, select [Thick cards (1.25

mm or more)].

Scanning at High Altitude [High Altitude Mode]

Select whether to enable or disable high altitude mode.

Enabling this setting allows you to use the scanner at 2,000 m

or higher altitudes.

1 Start up the Software Operation Panel.

For details, refer to "9.1 Starting Up the Software Operation Panel"

(page 163).

2 From the listing on the left, select [Device Setting 2] 

[High Altitude Mode].

3 Select whether to enable or disable [High Altitude Mode].

When you select [Enable], you can use the scanner at 2,000 m or

higher altitudes.

ATTENTION

Scanning speed slows down when you select [Thick cards (1.25

mm or more)].
