Basic adjustment

●

more...

●

Headphone volume

Adjust the headphone volume.

●

Auto volume

Reduces volume differences (for advertisements that

are too loud)

●

AV output signal

Allows you to indicate which sound is output via the

AV socket for dual sound programs: Sound1 (e.g. main

language), sound 2 (e.g. foreign language) or sound

1+2 (both simultaneously).

NOTE

• Selectable items vary depending on the received broadcasts.

●

Maximum volume

Determines the maximum volume that can be set.

●

Maximum switch on volume

Allows you to specify the volume that the TV is set when

switched on with the mains switch.

●

Balance

Set stereo balance so that the volume impression is

identical on the left and right.

●

Clear Voice

If Clear Voice is activated, the sound of the current

programme is automatically output with optimum

comprehensibility when speech is detected.

●

SPDIF mode

Allows you to choose between PCM or Dolby Digital

audio output.

Stations settings

In this item you can find all settings concerned with

station search for TV and DVB radio as well as functions

for creating and editing the various stations list.

1 Press MENU.

2 Select Setup→Stations, the next screen appears:

3 Select the station adjustment you want to adjust:

●

Automatic scan TV+Radio

In this adjustment, with the search wizard, you can

search/update new stations.

The current search settings will be displayed. If you

want to change these search settings:

Select Change search settings, press OK and wizard

will ask you for search settings.

If you agree with these settings, select Start search/

update and press OK to start scan.

NOTE

• You have to repeat the initial installation (see page 9) and

automatically search new ones, if you want to delete all

existing stations.

●

Manual Scan TV

If you want to adapt the parameters of an existing

station, first select the appropriate station.

1 Select Manual Scan TV and press OK, the next

screen appears:

2 Select the menu item Signal source to decide in

which area you want to search for stations.

Depending on the selected source, various setting

possibilities will be available.

3 Select Search to start search for next station.

4 Select Store to save station.

NOTE

• Only stations for the selected signal source can be saved,

which do not already exist in the station list.

Status bar for manual search

Status bars are displayed for manual search, which

show the reception quality of the individual stations

during the station scan. The markers in all bars

should preferably be in the green area.

C/N: (Carrier/Noise) The bar shows the signal to

noise ratio. The value indicated in dB should be

preferably high.

Level: The bar shows the receiving level of the

station. The value displayed in dBμV should be

preferably high.

BER: (Bit Error Rate) The bar shows the bit error

rate of the station. The value for BER should be as

low as possible.
