1-2

Connecting AC Power

Run your computer using AC power, rather than battery power, for

the first time. This ensures that you will not lose power while you

complete the Windows setup operation.

• Use only the AC adapter supplied with your computer, or

supplied by your computer vendor. You can damage your

computer if you try to use an AC adapter not approved for use

with this system.

• When removing the AC power cord from a wall outlet, grip the

plug and pull it from the socket. Never remove the power cord

from the outlet by pulling on the cord. Always grip the plug.

1. On the front edge of the computer, slide the display cover latch to the right and

raise the cover.

Display Cover Latch

2. Plug the cable from the AC adapter into the AC adapter jack on the rear side of

the computer.

To power outlet

AC adapter

AC adapter jack

3. Connect the power cord to the AC adapter.
