APPENDIX

Wiring protection

For installation Class T, Class J, or Class CC fuse or UL 489 Molded Case Circuit Breaker (MCCB) according to the local

directives must be provided.

Maximum allowable rating by US National Electrical Code. Exact size must be chosen for each installation.

For wiring protection of the converter unit (FR-CC2) refer to the FR-CC2 Instruction Manual-

A.1.3 Short circuit ratings

 200V class

Suitable for use in a circuit capable of delivering not more than 100kA rms symmetrical amperes, 264V maximum.

 400V class

Suitable for use in a circuit capable of delivering not more than 100kA rms symmetrical amperes, 550V or 600V

maximum.

A.1.4 Machinery directive

The frequency inverter itself is not a machine in the spirit of the EU machinery directive. The start up of the frequency

inverter in a machine is prohibited so long until it has been confirmed that the entire machine complies with the provisions

of Directive 98/37/EC (from 29.12.2009 Machinery Directive 2006/42/EC).

FR-A820-

00046

(0.4K)

00077

(0.75K)

00105

(1.5K)

00167

(2.2K)

00250

(3.7K)

00340

(5.5K)

00490

(7.5K)

00630

(11K)

00770

(15K)

00930

(18.5K)

01250

(22K)

01540

(30K)

Rated fuse voltage [V] 240V or more

Fuse Maximum

allowable rating [A]

Without power

factor improving

reactor

15 20 30 40 60 80 150 175 200 225 300 350

With power factor

improving reactor

15 20 20 30 50 70 125 150 200 200 250 300

Molded case circuit breaker (MCCB)

Maximum allowable rating [A]

15 15 25 40 60 80 110 150 190 225 300 350

FR-A820-

01870

(37K)

02330

(45K)

03160

(55K)

03800

(75K)

04750

(90K)

Rated fuse voltage [V] 240V or more

Fuse Maximum

allowable rating [A]

Without power

factor improving

reactor

400 500 500 — —

With power factor

improving reactor

350 400 500 600 700

Molded case circuit breaker (MCCB)

Maximum allowable rating [A]

450 500 700 900 1000

FR-A840-

00023

(0.4K)

00038

(0.75K)

00052

(1.5K)

00083

(2.2K)

00126

(3.7K)

00170

(5.5K)

00250

(7.5K)

00310

(11K)

00380

(15K)

00470

(18.5K)

00620

(22K)

00770

(30K)

Rated fuse voltage [V] 500V or more

Fuse Maximum

allowable rating [A]

Without power

factor improving

reactor

6 1015203040708090110150175

With power factor

improving reactor

6 1010152535607090100125150

Molded case circuit breaker (MCCB)

Maximum allowable rating [A]

15 15 15 20 30 40 60 70 90 100 150 175

FR-A840-

00930

(37K)

01160

(45K)

01800

(55K)

02160

(75K)

02600

(90K)

03250

(110K)

03610

(132K)

04320

(160K)

04810

(185K)

05470

(220K)

06100

(250K)

06830

(280K)

Rated fuse voltage [V] 500V or more

Fuse Maximum

allowable rating [A]

Without power

factor improving

reactor

200 250 300 — — ―――――――

With power factor

improving reactor

175 200 250 300 350 400 500 600 700 800 900 1000

Molded case circuit breaker (MCCB)

Maximum allowable rating [A]

225 250 450 450 500 600 800 900 1000 1200 1200 1200

FR-A846-

00023

(0.4K)

00038

(0.75K)

00052

(1.5K)

00083

(2.2K)

00126

(3.7K)

00170

(5.5K)

00250

(7.5K)

00310

(11K)

00380

(15K)

00470

(18.5K)

Rated fuse voltage [V] 500V or more

Fuse Maximum allowable rating [A]

6 1010152535607090100

Molded case circuit breaker (MCCB)

Maximum allowable rating [A]

15 15 15 20 30 40 60 70 90 100
