4-13

10.

Select Input/Output Range in the Resource settings and click on the

Changing Setting button.

11.

Select the value between 0100 and 03A0 by pressing the

button so that

the conflicts information indicates No conflicts.

12.

Click on the OK button twice and then click on the YES button.

Setting the COM Port

Some PC cards use the COM3 or COM4 port address. The COM1 and COM2

ports of your notebook are already used by other devices, and COM3 or COM4

may conflict with those ports.

When a PC card uses the COM3 port address, go to the Advanced page of the

Setup utility and disable the field COM 1 Port.

When a PC card uses the COM4 port address, go to the Advanced page of the

Setup utility and disable the field COM 2 Port (For IR).
