Quick Start

REMOVING HAND STRAP

The hand strap is ideal for one-handed operation, which requires safe and convenient

hold of the mobile computer.

Warning: When in use, make sure the hand strap is well hooked.

When the hand strap is not desired or you need to install / remove the main battery,

release it from the mobile computer by following these steps:

1) Hold the mobile computer still and upside down.

2) Unhook the hand strap from the bottom.

Figure 3: Removing the Hand Strap
