• Wheninstalling,removingormovingthemonitor,ensurethatthisiscarriedoutbyatleast2people.

• Besuretouseawall-mountbracketdesignedordesignatedformountingthemonitor.

• Thismonitorisdesignedtobeinstalledonaconcretewallorpillar.Reinforcedworkmightbenecessaryforsomematerials

suchasplaster/thinplasticboard/woodbeforestartinginstallation.

Thismonitorandbracketmustbeinstalledonawallwhichcanendureatleast4timesormoretheweightofthemonitor.

Installbythemostsuitablemethodforthematerialandthestructure.

• ToattachaVESA-compliantmountingbracket,useM6screwsthatare5/16inch(8mm)to3/8inch(10mm)longerthanthe

thicknessofthemountingbracket.

• Whenmovingthemonitor,besuretoholditwiththehandlesandtheunitbottom.DonotholdtheLCDpanel.Thismaycause

productdamage,failure,orinjury.

• Aftermounting,pleasecarefullyensurethemonitorissecure,andnotabletocomeloosefromthewallormount.

• DonotuseanyscrewholesotherthanVESAholesforinstallation.

Model PN-E702

Powerrequirement AC100V-240V,2.8A,50/60Hz

Operatingtemperature

32°Fto104°F(0°Cto40°C)

Operatinghumidity 20%to80%(nocondensation)

Powerconsumption(Maximum) 235W[WhenPN-ZB01(optional)isattached:240W]

Dimensions(excludingprotrusions) inch(mm)

Approx.63-9/16(W)x3-15/16(D)x37-5/16(H)(1,615x100x947)

Weight lbs.(kg)

Approx.110.2(50)

[PN-ZB01(optional):

Approx.1.102(0.5)

]

* TemperatureconditionmaychangewhenusingthemonitortogetherwiththeoptionalequipmentsrecommendedbySHARP.

Insuchcases,pleasecheckthetemperatureconditionspeciedbytheoptionalequipments.

Asapartofourpolicyofcontinuousimprovement,SHARPreservestherighttomakedesignandspecicationchangesforproductimprovement

withoutpriornotice.Theperformancespecicationguresindicatedarenominalvaluesofproductionunits.Theremaybesomedeviationsfrom

thesevaluesinindividualunits.

Specications

Mounting Precautions (For SHARP dealers and service engineers)
