Basic Operation

-53

4 Press .

• The cursor shifts to the sub menu.

5 Press or to select

the setting of the item

displayed in the sub menu.

6 Press .

• The item selected is set.

Note

• Some adjustment items will display

a confirmation message.

When setting an item, press

to select “Yes” or “OK” and then

press

7 Press .

• The menu will disappear and the

adjustment is stored.

Sub menu

PG-M25X#E#p50_64.p65 02.4.29, 3:15 PM53
