PG-D4010X/D3750W
True XGA/WXGA Data Projectors
Ceiling MountsCable
AN-C3CP2
3-RCA to 15-pin
D-sub cable
(10’ (3 m))
Lamp
AN-D400LP
USB Remote
Receiver
AN-MR2
AN-TK201
For high ceiling
installation
AN-TK202
For standard
ceiling installation
AN-60KT
Installation
adaptor
Dimensions (PG-D4010X/D3750W)
PG-D4010X/D3750W
Optional Accessories Rear terminals (PG-D4010X)
Note: Some of the optional accessories may not be available depending on the region.
Please check with your nearest Sharp Authorized Projector Dealer or Service Center.
Specifications
Model
Display devices
Resolution
Brightness
Contrast ratio
Lens F number
Zoom
Focus
Picture size
Projection distance
Input signals Computer RGB
DTV
Input terminals HDMI
DVI-I (Compatible with HDCP)
Computer / Component (mini D-sub 15 pin)
S-Video (mini DIN 4 pin)
Video (RCA)
Audio (ø3.5mm stereo minijack)
Audio (RCA)
Output terminals
Computer / Component (mini D-sub 15 pin)
Audio (ø3.5mm stereo minijack)
Control and
LAN (RJ-45)
communication USB (Type B)
terminals
RS-232C (mini D-sub 9 pin)
Horizontal frequency
Vertical frequency
Speakers
Fan noise
Projection lamp
Lamp life
On-screen display languages
Rated voltage
Rated frequency
Input current
Power consumption (Standby)
Operation temperature
Cabinet
Dimensions (main body only) W x H x D
Weight (appprox.)
Supplied accessories
PG-D4 0 1 0X PG-D3 7 5 0W
F 2.5 to 2.7
Manual, x 1.15 (f = 21.0 to 24.2 mm)
Manual
40” (102 cm) to 500” (1,270 cm)
1080P / 1080I / 720P / 576P / 576I / 540P / 480P / 480I
NTSC / PAL / SECAM
1
1
1
1 (L/R)
1
1 (variable audio output)
1
1
1
15 to 110 kHz
45 to 85 Hz
5 W x 2 (Stereo)
37 dB (Bright), 30 dB (Eco+Quiet)
330 W
3,000 hours (Eco+Quiet)
English, German, Spanish, Dutch, French, Italian, Swedish, Portuguese, Russian, Polish, Hungarian, Turkish, Arabic, Persian, simplified Chinese, Korean, Japanese
AC100 to 240V
50 / 60Hz
4.5 A
429 W (10.2 W) with AC 100V, 408 W (10.8 W) with AC 240V
41°F to 95°F (+5°C to +35°C)
Plastic
15
3
/4” x 4
15
/16” x 13
13
/64” (400 x 100 x 335 mm)
12.8 lbs. (5.8 kg)
Remote control, Two R-6 batteries, Power cord (6’ (1.8 m)), RGB cable (10’ (3.0 m)), Operation manual, CD-ROM
0.7” DLP
®
chip x 1
XGA (1,024 x 768)
4,200 ANSI lumens
2,500:1
40” (1.2 to 1.4 m), 100” (3.0 to 3.4 m), 500” (14.9 m)
UXGA*
1
*
2
/ WSXGA+*
1
*
2
/ SXGA+*
1
/ SXGA*
1
/ WXGA*
1
/ XGA / SVGA / VGA
Mac 21” / 19” / 16” / 13”
—
1
1
0.65” DLP
®
chip x 1
WXGA (1,280 x 800)
3,700 ANSI lumens
2,200:1
40” (1.3 to 1.5 m), 100” (3.2 to 3.7 m), 500” (16.1 m)
UXGA*
1
*
2
/ WSXGA+*
1
*
2
/ SXGA+*
1
/ SXGA*
1
/ WXGA / XGA / SVGA / VGA
Mac 21” / 19” / 16” / 13”
1
—
2
© SHARP CORP. (JAN. 2009 PRINT) I E
PG-D4010X
Top
Units: inches (mm)
Front
Back
The New DLP
®
Projectors Provide Enhanced Convenience and
Reliability As Well As Superb Performance with High-Quality,
High-Brightness Picture Using Brilliant Color
™
Technology
DVI-I Computer/Component
Audio
Audio out
Monitor out
Computer/Component
USB
RS-232C
S-Video
Video
Audio
LAN
(PG-D3750W) (PG-D3750W)
The PG-D3750W is identical in appearance to the PG-D4010X with the exception of the model number indication.
M4
M4
M4
M4
1
1
/
2
(38)
3
33
/
64
(89)
6
49
/
64
(171.5)
7
5
/
64
(179.75)
15
/
64
(5.75)
2
61
/
64
(75)
4
5
/
8
(116.25)
1
13
/16
(45.75)
3
15
/16 (100)
1
43
/
64
(42.2)
4
17
/
32
(115)
1
/
8
(3) 15
3
/4 (400)
4
17
/32
(115)
3
23
/64
(85)
13
3
/
16
(335)
1
/
4
(6)
Design and specifications are current as of January 2009, but are subject to change without notice.
*
1
Compatible in intelligent compression
*
2
Compatible only with analogue RGB signals depending on the signal.
• DLP
®
and the DLP logo are resistered trademarks of Texas Instruments, and BrilliantColor™ is a trademark of Texas Instruments.
• All company and/or product names are trademarks and/or registered trademarks of their respective manufacturers. Sharp makes no warranties or representations of any kind with respect to these products.
• The lamp life may vary depending on the usage condition.
Sharp Electronics Central & Eastern Europe, a division of Sharp Europe
A-1020 Vienna, Handelskai 342, Phone: +43 / (0)1 / 7 27 19 - 0
Fax: +43 / (0)1 / 7 27 19 - 141, e-mail: ma[email protected]
more info under: www.sharp-cee.com
