BYPASS FEED (special paper)

MAKING COPIES

Set the number of copies and press the START ( ) key.

NOTE:

The bypass tray can be used to copy onto the two sides of paper manually.

When copying the second original, be sure to turn over the copy of the first original left to right

and place it into the bypass tray as shown in the illustration.

Second original

Copy of first original

Ar-M208_sec.book 43 ページ２００２年６月１３日　木曜日　午後２時３７分
