AR-235/275 DISASSEMBLY, ASSEMBLY AND MAINTENANCE - 7

Installation*Install so that the boss of the lever arm comes into the rib

of the shutter arm.

Installation*Install so that the cam transmit arm (1) comes under the

roller arm (2).

b. Separation sheet

∗

Slightly apply grease GP501MR (UKOG-0012QSZZ) around the

axis. One rice grain for each.

1)

2)

1)

2)

No. Part name

Service

items

Cycle Remarks

1 Pickup roller (Multi

bypass tray)

Check

50k

Changing criteria

for parts: 50k

2 Separation roller (Multi

bypass tray)

Check

50k

Changing criteria

for parts: 50k

3 Separation sheet (Multi

bypass tray)

Check

50k

Changing criteria

for parts: 50k

L

C

K

T

O

K

O

2)

3)

1)

4)

5)

2

1

1)

2)

3)

3
