PRINTER SHARING

Settings in Windows NT 4.0

If your operating system is Windows NT 4.0, configure settings as follows in the printer properties after installing the

printer driver. For the procedure for installing the printer driver, see "1. INSTALLING THE SOFTWARE (THAT

ACCOMPANIES THE MACHINE)" in the "Software setup guide".

Click the [Start] button, select

[Settings] and then click [Printers].

Click the [SHARP AR-XXXX] printer

driver icon and select [Properties]

from the [File] menu.

The printer properties will appear.

Click the [Ports] tab and then click the

[Add Port] button.

The [Printer Ports] dialog box will appear.

Select [Local Port] in the "Available

Printer Ports" list, and click the [New

Port] button.

The "Port Name" dialog box will appear.

Enter "\\(name of server connected to

machine)\(name of shared printer)",

and click the [OK] button.

Click the [Close] button in the [Printer

Ports] dialog box.

Click the [OK] button in the printer

properties window.

name of server connected to machine

name of shared printer
