SCANNER AND FAX FUNCTIONS

124

Image orientation and standard original loading

orientation

When using the document glass, the original should be placed face down. Center the

original vertically on the document glass with the top edge at the left edge of the

glass.

When using the RSPF, the original should be placed face up in the middle of the

document feeder tray, with the top of the original to the right. (The network scanner

function cannot scan both sides of an original placed in the RSPF.)

Long horizontal originals (from A4) can only be placed as shown below.

For this reason, the scanned image will be rotated 90° when viewed on a computer.

Document glass RSPF Scanning result
