Sharp AR-155 Specifikace stáhnout pdf (Strana 27)

REDUCTION/ENLARGEMENT/ZOOM

Copies can be reduced down to 25% or enlarged up to 400%. (When the SPF/RSPF

is being used, the zoom copy ratio range is 50% to 200%.) The [ZOOM] key can be

pressed to quickly select a ratio from among eight preset ratios. In addition, the [ ]

key ( ) and [ ] key ( ) can be pressed to select the ratio in increments of 1%.

Check the original and paper size, and place the original(s).

Press the [ZOOM] key.

Press the [ZOOM] key and/or [ ] key ( ) or [ ] key ( ) to

select the desired copy ratio and then press the [OK] key.

Selecting a preset ratio

The preset ratios change as follows each time the

[ZOOM] key is pressed:

"100%" → "86%" → "70%" → "50%" → "25%" →

"400%" → "200%" → "141%"

("100%" → "78%" → "64%" → "50%" → "25%" →

"400%" → "200%" → "129%").

Fine adjustment of the ratio

The ratio can be adjusted from 25% to 400% in

increments of 1%.

Use the [ ] key ( ) or the [ ] key ( ) for

fine adjustment.

Select the number of copies and any other copy settings, and

then press the [START] key ( ).

The copy will be delivered to the paper output tray.

• To return the ratio to 100%, press the [ZOOM] key until 100%

appears.

• Press the [ZOOM] key to set the approximate ratio, then press the

[ ] key ( ) or [ ] key ( ).

• To decrease or increase the zoom ratio rapidly, hold down the [ ]

key ( ) or [ ] key ( ).

The ratio will stop changing at each of the preset ratios. To continue

changing the ratio, release the key and then hold it down again.

COPY RATIO

- 100% +

1,2,3,

SP. FUNC

1,2,3,

SP. FUNC

A4 TO B5

- 86% +

1,2,3,

SP. FUNC

ZOOM

- 99% +

Note
