PRINTING MULTIPLE PAGES ON ONE PAGE

This feature allows you to reduce and print two, four, six, eight or sixteen document

pages on a single sheet of paper.

To use this function, open the printer driver setup screen and select the number of

pages per sheet (2-Up, 4-Up, 6-Up, 8-Up, 9-Up, or 16-Up) in "N-Up Printing" in the

"Main" tab.

The order of the pages can be changed in the "Order" menu.

☞ See "BASIC PRINTING" (p.61) for details on how to open the printer driver.

For example, when "2-Up" or "4-Up" is selected, the result will be as follows

depending on the selected order.

If you select the "Border" checkbox, borderlines will be printed around each page.

The "N-Up Printing" setting is not available when "Zoom" is selected.

☞"FITTING THE PRINTED IMAGE TO THE PAPER" (p.68)

N-Up Left to Right Right to Left

[2-Up]

N-Up

Right , and Down Down , and Right

Left , and Down Down , and Left

[4-Up]

Examples for 2-Up and 4-Up are shown here. The order of 6-Up, 8-Up,

9-Up, and 16-Up is the same as 4-Up. The order can be viewed in the

print setting image in the printer driver setup screen.

☞"PRINTER DRIVER SETTINGS" (p.64)
