C: Misfeed in the transport area

Lower the fusing unit release lever.

See "B: Misfeed in the fusing area" (p.66).

Open the front cover.

To open the front cover, see "INSTALLING THE TD CARTRIDGE" (p.10).

Rotate the roller rotating

knob in the direction of the

arrow and gently remove

the misfed paper from the

exit area.

Raise the fusing unit release lever, close the front cover and

then close the side cover by pressing the round projections

near the side cover open button. The misfeed ( ) indicator will

go out and the start ( ) indicator will light up.

When closing the covers, be sure to close the front cover securely and

then close the side cover. If the covers are closed in the wrong order, the

covers may be damaged.

Roller rotating knob
