Follow the installation procedure below to use the unit properly.

SETUP PROCEDURE

When using the unit for the first time, setup the unit following the procedure shown

below.

* If you are only using the unit for copying, skip this step.

If the unit does not function properly during setup or use, or if a function

cannot be used, see "TROUBLESHOOTING THE UNIT" (p.62).

1 Open the package, and make sure that all the accessories are

supplied with the unit. (p.8)

2 Remove the protective materials. (p.9)

8 Now, you can copy (p.46), print (p.35) or scan (p.36) your

document.

3 Install the TD cartridge. (p.10)

4 Load the paper in the paper tray (p.15) or the multi-bypass

tray

. (p.17)

5 Plug the other end of the power cord into the nearest outlet. (p.12)

6 Install the software.* (p.19)

7 Connect the interface cable* (p.25) and turn on the unit. (p.12)

SETTING UP THE UNIT
