–199–
2-1 Digital colour printers
UP-D2600
Digital colour printer
•Photo-quality prints with Sony dye transfer sublimation
thermal printing technology with over 16 million color
variations •Advanced thermal head provides 310 dpi (dots
per inch) high resolution and the digital process provides
high-quality prints with a maximum of 1365 (H) x 1024 (V)
dots (standard) and 1646 (H) x 1024 (V) dots (large) •By
using the optional UPC-2045 Self-laminating Color Print
Pack, the prints are outputted with a laminating layer with
three types of finishes: Glossy, Texture and Matte •ICC
profiles supplied •Near A6-size print (130 x 88 mm (5 1/8 x 3
1/2 inches)) can be printed in approximately 50 seconds
•Laminated type (UP-2045) can be printed out in 70 seconds
•Equipped with a Parallel (IEEE-1284) interface •Supports
the bi-Centronics ECP mode •Three color plane memories to
free the computer after the image is transferred to the printer
•Compatible with Windows NT 4.0, Windows 95/98 •Picture
scaling function •200 (standard) /150 (large)-sheet paper
feed capacity •Front panel operation •Complies with the
MDD
Supplied accessories: AC Power Cable (1)
Paper Tray (2) (Standard and Large)
Paper Cover (1)
Roller Cleaning Kit (1)
Operation Manual (1)
CD-ROM with printer driver included (1)
(for Windows 95/98, Windows NT 4.0 and
Photoshop plug-in for Windows 95/98)
Optional accessories Color Printing Pack UPC-2010 (for 200 prints)
Black and White Printing Pack UPC-2020
(for 200 prints)
Self-laminating Color Printing Pack UPC-2045
(for 120 prints)
Self-laminating Color Printing Pack UPC-2040A
(for 120 prints)
Color Postcard Printing Pack UPC-2070E
(for 150 prints)
16-split Self-adhesive Pre-cut Color Printing Pack
UPC-20S16 (for 200 prints)
4-split Self-adhesive Pre-cut Color Printing Pack
UPC-20S04 (for 200 prints)
Self-adhesive Color Printing Pack
UPC-20S01 (for 200 prints)
Paper Ejector UPA-2001
Roller Cleaning Kit UPA-2003
Specifications
Printing method: Dye transfer sublimation thermal printing
Resolution: 310 dpi or 155 dpi selectable
Gradation: 256 gradations for Yellow, Magenta, Cyan
Over 16.7 million colors per dot
Printing paper size: UPC-2010/2020/20S01/20S04/20S16: 130 × 88 mm
(5
1
⁄8 × 3
1
⁄2 inches)
UPC-2045/2040A/2070/2070E: 148 × 100 mm
(5
7
⁄8 × 4 inches)
Printed picture size: Standard: max. 112 × 84 mm (4
1
⁄2 × 3
3
⁄8 inches)
Large: max. 135 × 84 mm (5
3
⁄8 × 3
3
⁄8 inches)
Picture elements: Standard: 1365 × 1024 dots
Large: 1646 × 1024 dots
Picture memory: 3 color planes (6 MB)
Printing time: Approx. 50 seconds
(When using the UPC-2045: Approx. 70 seconds,
UPC-2040A: Approx. 97 seconds)
Interface port: IEEE standard 1284-1994 (Compatible, Compatible
Nibble and ECP modes)
Paper tray capacity: Standard size paper tray: 200 sheets
(UPC-2010/2020/20S01/20S04/20S16)
Large size paper tray: 120 or 150 sheets
(UPC-2045/2040A/2070/2070E)
Picture scaling function: VGA mode (640 × 480 dots), SVGA mode (800 × 600
dots), XGA mode (1,024 × 768 dots)
Power requirements: 220 to 240 V, 50/60 Hz
Power consumption: Approx. 1.0 A / 220 V
Dimensions: 370 (W) × 125 (H) × 417 (D) mm
(14
5
⁄8 × 5 × 16
3
⁄4 inches)
Mass: Approx. 9.5 kg (20 lb 15 oz)
Safety regulations: EN60950, EN60601-1, MDD, CE mark
STILL IMAGE
PRODUCTS
